Bianco Submersible Pump BIA-B42A

inc. GST

Quick Overview

Submersible high head pump designed for AWTS and rainwater tanks. Fitted with noryl impellers and stainless steel strainer. AS/NZS4020 Approved for drinking water, 5 star energy rating, 550 watts.
• Glass Filled Nylon pump body and Stainless Steel
cover for strength and lightness.
• Easy grip, nylon carry handle.
• Dual mechanical seals (Carbon ceramic on pump
side / silicon carbide in oil bath on motor side).
• 3 Stage High Head pump with durable Noryl
• Elevated (83mm) suction intake with Algae-Proof
slotted strainer.
• 10m Power lead and automatic Float Switch. All
cables to H07RNF standard.
• 240V Single Phase , 0.55kW 5 Star efficient motor.
Built in auto-resetting thermal overloads
• Benefits
• Strainer design improves water flow and prevents
blockage from algae growth.
• Elevated intake draws oxygenated water from higher in
tank and avoids sludge layer.
• Leads to improved water quality with lower algae and
anaerobic mater for better smelling water and cleaner
clothes washing.
• Quality pump materials assist with longer pump life
while still being light to lift and lower.
• High Head pump with low energy usage
• Applications
• Domestic pressure systems (with optional Press
• Pumping Clean and pre-treated water.
• AWTS – Automated Water Treatment Systems pump
out to dripper beds.
• De-watering of cellars, basements and garages.
Electrical data:
Rated voltage: 240V
Mains frequency: 50 Hz
Rated output: 550W
Current: 4.0 amps
Capacitor: 20 uF
Motor duty: Continuous
Motor type: Asynchronous
Motor protection: In-built thermal overload
Ingress protection: IP 68
Insulation class: F
Power cable length: 10 m H07RNF
Net weight: 12 kg
Dimensions: 171Lx162Wx461H (mm)
2 Year Bianco Pumpz Warranty
